Analysis in R: Create Heat Maps Easily! The “heatmap3” package

RAnalytics

Heatmap is a way to visually display the size of numbers and objects by color.

Note that the ggplot2 extension package can also plot heatmaps. Click here to read the full article.

Package version is 1.1.9. R version 4.2.2 is confirmed.

スポンサーリンク
Sponsored Link

Install Package

Run the following command.

#Install Package
install.packages("heatmap3")

Execute command

Here are three examples. When using Rstudio, if the plot area is too small, the message “Figure margins too large” may appear and the heat map may not be displayed. In this case, please increase the plot area sufficiently and re-run the command.

#Loading the library
library("heatmap3")

#Example 1 Displaying data in color bars
temp <- c(-3, 2, 1, 2, 1.2, -1.2)
col <- colByValue(temp, col = colorRampPalette(c('chartreuse4', 'white', 'firebrick'))(1024),
                  range = c(-2,2))

#Example 2 Group color at the top of the heatmap
set.seed(123456789)
###Creating Data Examples#####
rnormData <- matrix(rnorm(1000), 40, 25)
rnormData[1:15, seq(6, 25, 2)] = rnormData[1:15, seq(6, 25, 2)] + 2
rnormData[16:40, seq(7, 25, 2)] = rnormData[16:40, seq(7, 25, 2)] + 4
########

###Set row and column names for created data#####
#colnames
colnames(rnormData) <- c(paste("Control", 1:5, sep = ""),
                         paste(c("TrtA", "TrtB"),
                               rep(1:10,each = 2), sep = ""))
#rownames
rownames(rnormData) <- paste("Probe", 1:40, sep = "")
########

#Specify the group colors to be displayed at the top of the heatmap. You can change the color here.
ColSideColors <- c(rep("steelblue2", 5), rep(c("brown1", "mediumpurple2"), 10))

#Plot heatmap
heatmap3(rnormData, ColSideColors = ColSideColors, showRowDendro = FALSE)

#Example 3 Using the "showAnn" function to display data details at the top of the heatmap
###Creating Data Examples#####
annData <- data.frame(mtcars[,c("mpg","am","wt","gear")])
annData[,2] <- as.factor(annData[,2])
annData[,4] <- as.factor(annData[,4])
########

#Plot heatmap
heatmap3(t(mtcars), ColSideAnn = annData,
         ColSideFun = function(x){showAnn(x)},
         ColSideWidth = 1.2, balanceColor = TRUE)

Output Examples

Example 1

Example 2

Example 3


I hope this makes your analysis a little easier !!
